Laying and maintenance tips

Technical features

STANDARD

ISO 10545/3

ISO 10545/6

ISO 10545/9

ISO 10545/12

ISO 10545/13

ISO 10545/14

DIN 51130-04

DIN 51097

Pendulum BS 7976-2

LEED CERTIFICATION 4.1

ISO 14001 - ISO 9001

VOC Emission

Declaration of Contents

EPD

SDS

BPD3

HPD

use

installation

recommended adhesive

recommended joints

recommended fillers

cleaning at the end

of installation

general cleaning

(installed tiles)

calibers (real size)

Colours

Floor, wall – indoor, outdoor.

For an even, smooth shading effect when laying, alternate material from several different boxes.

Adhesive for porcelain stoneware.

2mm joints. Use wedges to fix the caliber differences in work size between tiles.

Cement-based grout / epoxy grout.

CEMENT-BASED GROUT: Buffered acid (e.g. DETERDEK PRO by FILA, or similar). Wet the floor with water, dilute the product 1:5 with water

and pour it on the floor. Wait for 2 or 3 minutes then use a white scotch brite pad and rinse well with clean water.

EPOXY GROUT: Alkaline detergent (e.g. FILA CR10 by FILA). FILA CR10: apply pure, wait for 30 minutes then use a green scotch brite pad.

SILICONE: Solvent for silicone (e.g. FILA ZERO SIL.). Pour it straight onto the stain, wait for 20 minutes and remove the mark using

scotch brite.

PAINT: Can usually be removed using water, but if resin-based paints or particular enamels have been used, it is best to ask the manufacturer

which solvent is most suitable.

RUST: stain remover es. FILA NO RUST. Apply the product onto the stain, leave for 15 minutes, remove the residue and rinse thoroughly.

You are recommended to use ordinary neutral detergent diluted in water. Avoid using acid or alkaline products, waxes and/or impregnants.

During ordinary cleaning it is recommended to use extremely abrasive items (such as scourers and iron or steel sponges) as little as possible.

This recommendation must be adhered to rigorously in the case of tiles with a glossy surface finishing as they are more susceptible to the risk

of scuffs, scratches and loss of shine, etc. In the event of heavy dirt or particularly textured surfaces, use an alkaline detergent and rinse after

washing. For large surfaces, the use of a floor washing machine is recommended. During every-day cleaning procedures, it is necessary to

remember that certain types of dirt (dust, sand) increase the abrasive effect of foot-traffic. Therefore we recommend that you avoid bringing in

this type of dirt, which comes in from the outside, by placing a door-mat at the entrance.

600 mm x 600 mm

FEATURES

water absorption

resistance to deep abrasion

thermal shock resistance

frost resistance

acids and alkalis resistance

VALUE REQUIRED

FOLDED

in conformity

in conformity

no alteration

no alteration

A

class 4

R9

–

51 dry

41 wet

15% recycled material

available upon request

available upon request

available upon request

available upon request

available upon request

available upon request

KG·PAL

SQM·PAL

914,00

43,20

–

–

< 0,5%

<175 mm3

no alteration

no alteration

stains resistance

slip resistance

min B

classe 3

medium

6÷10°

10÷19°

19÷27°

27÷35°

> 35°

–

values

R9

R10

R11

R12

R13

V1

uniform variation

Packing

SIZE

60·60 cm

skirting 3,8·60 cm

PCS·SQM

2,77

–

PCS·BOX

3

10

SQM·BOX

1,08

6,00 ml

BOX·PAL

40

–

KG·BOX

22,85

5,00

For information about the available grouts, please contact the sales department.

458

FOLDED

FOLDED

459
