Biogas technology – system component

s

Fermenter heater BIOFLEX CNW BG 60/6

6

completely in stainless stee

l

Worksheet BGT 1.800:

End connector GRAPA-S with walll duct for concrete fermente

r

Worksheet BGT 1.810

:

End connector GRAPA-S with

flange plate for steel- or concrete fermente

r

Article

Material

Dimensions Article-No.

Pipe BFX CNW 60/66*

1.4404

DN 50

1014439

End connector GRAPA-S

1.4301

DN 50 / R 2" 1014621

male thread R 2"

End connector GRAPA-S

1.4301

DN 50 / R 2" 1014608

incl. wall duct Ø 89 mm

Elbow screw fitting

1.4301

DN 50

1014617

Double nipple R 2 with flange plate

1.4301

DN 50

1014613

Package unit pipe support

1.4301

200/250

1014631

(contains 10 pieces pipe support RBF type A)

Pipe support RBF 60 type B

1.4301

200/250

1014626

Gasket insert 2 x type A WD 55-64

1.4301

55-64/125

1014620

Core drilling Ø 125 m

m

Gasket insert 2 x type A WD 85-94

1.4301

85-94/150

1014623

Core drilling Ø 150 m

m

Fixing set incl. dowel BS 10

1.4301/Nylon

Borehole

1014629

Ø 12 m

m

Through-/repair-connector/elongation

1.4301

DN 50

1014630

type GRAPA-S

Installation tool for end connector

Steel

DN 50

1014677

gasnitrided

Installation tool for repair-connector

Steel

DN 50

1014687

gasnitrided
