TECH

INFORMAZIONI TECNICHE

TECHNICAL INFORMATION

312

WIDE 313

AUTOLEVELING 318

CONSIGLI DI POSA E PULIZIA / INSTALLATION AND CLEANING ADVICE 318

CARATTERISTICHE TECNICHE / TECHNICAL CHARACTERISTICS 321

ECOSOSTENIBILITA’ E CERTIFICAZIONI / ECO-SUSTAINABILITY AND CERTIFICATIONS 325

GUIDA ALLA CONSULTAZIONE / CONSULTATION GUIDE 325

CONDIZIONI GENERALI DI VENDITA / GENERAL SALES TERMS AND CONDITIONS 326

IMBALLI / PACKAGING 329

CERAMIC R-EVOLUTION

Il progetto WIDE ABK parte dalla rivoluzionaria tecnologia produttiva CONTINUA+, che permette di produrre lastre in gres porcellanato robuste e leggere allo stesso tempo, grazie

allo spessore ridotto di 6 fino alla dimensione record di 160x320 cm.

Il nuovo sistema di pressatura prevede la compattazione a secco delle materie prime e consente di ottenere superfici particolarmente apprezzabili sia per la qualità estetica che per le

performance tecniche.

ABK’s WIDE collection consists of tough yet lightweight porcelain slabs with a thickness of just 6 and a record size of 160x320 cm produced using the revolutionary CONTINUA+

technology.The new pressing system involves dry compaction of raw materials and is able to produce surfaces that combine excellent aesthetic quality with outstanding technical

performance.

& STRONG

WIDE è perfettamente idoneo

sia per il rivestimento che per

la pavimentazione, in ambito

residenziale e commerciale.

Lo spessore 6 mm consente di

mantenere un’ottima resistenza al

carico di rottura reale.

WIDE is ideal as both a floor and

wall covering in residential and

commercial projects.The 6 mm

thickness enables it to maintain

excellent breaking strength in real

situations.

PESO

WEIGHT

ABK 9 mm = 19,5 Kg x mq

ABK 6 mm = 15,0 Kg x mq

NEW DIMENSIONS

LITE GOES

Lo spessore 6 mm consente

di ridurre il peso per mq

con interessanti vantaggi in

termini di maneggevolezza

e movimentazione.

The 6 thickness results in a

reduced weight per square

metre, bringing significant

advantages in terms of ease

of working and handling.

IS LEVELING

La combinazione fra impasto

ad elevata plasticità, spessore e

grande dimensione, dona parti-

colare elasticità al prodotto, per

ottenere risultati di posa sempre

impeccabili.

The combination of a body with

high plasticity, thickness and

dimensions makes for a highly

elastic product that delivers consi-

stently flawless results.

EASY AS

La formulazione dell’impasto,

unita alla compattazione a

secco e alla cottura in forni di

nuova concezione, genera un

gres particolarmente facile

da tagliare e lavorare.

The chemical formulation of

the body combined with the

raw material dry compaction

process produces a porcelain

slab that is easy to cut and

work with.

MEANS GREEN

L’impasto contiene il 40% minimo

di materie prime di qualità recu-

perate da altri processi produttivi,

per questo i prodotti WIDE pos-

sono essere accreditati all’interno

del sistema internazionale LEED.

As the body contains a minimum

of 40% high-quality raw materials

recycled from other production

processes, WIDE collection pro-

ducts qualify for LEED internatio-

nal certification.

indicatore di flessibilità

flexibility index

deflessione massima sotto carico di 350 N

maximum deflection under load of 350 N

lato/lenght 2400 mm

> 50 mm

lato/lenght 2800 mm

> 70 mm

lato/lenght 3200 mm

> 100 mm

Uno degli obiettivi del progetto WIDE è quello di fornire un materiale ceramico tecnologicamente avanzato facilmente utilizzabile in contesti anche molto diversi, per dimensione e per

destinazione d’uso. WIDE è un vero e proprio programma di formati, tutti rettificati, pensati per coprire a 360° le esigenze legate alla progettazione, a partire dagli spazi residenziali,

fino alle grandi opere in ambito pubblico e commerciale.

One of the aims of the WIDE project is to supply a hi-tech ceramic material that is easy to use in very different sizes and applications. WIDE comes in a large selection of sizes, all

rectified, ideal for uses ranging from residential through to large-scale works in public and commercial spaces.

EVERYWHERE YOU LIKE

Tenendo conto delle principali qualità del materiale, tra cui la robustezza, la resistenza agli sbalzi termici, oltre allo spessore contenuto e alla facilità di lavorazione, le

grandi lastre WIDE ampliano la destinazione d’uso del gres porcellanato. Sempre meno fughe e sempre più spazio alla creatività di progettisti e interior designers, che

grazie ai prodotti WIDE possono apprezzare la versatilità di una ceramica senza più confini.

Taking account of the material’s key qualities, including strength, thermal shock resistance, low thickness and ease of working, the WIDE large-size slabs extend the fields

of use of porcelain.The WIDE collection has fewer joints while givingenormous creative freedom to architects and interior designers, who appreciate the versatility of this

ceramic surface without limits.

PAVIMENTI INTERNI

INDOOR FLOORS

PIANI LAVORO CUCINE

KITCHEN COUNTERTOPS

RIVESTIMENTI INTERNI

INDOOR WALLS

TOP E FINITURE PER

AMBIENTI BAGNO

BATHROOM VANITY TOPS

AND SHELVES

FACCIATE ESTERNE

INCOLLATE E VENTILATE

GLUED AND VENTILATED

EXTERIOR FAÇADES

ELEMENTI DI ARREDO E

DESIGN PER INTERNI

INTERIOR FURNISHING

AND DESIGN ELEMENTS

PAVIMENTI AREE ESTERNE

OUTDOOR FLOORS

313
