UV sterilizers
T
R
E
A
T
M
E
N
T
S
Y
S
T
E
M
S
UV 300 - UV 600
UV 300 AL
STERILIZERS WITH BALLAST
CODE
EA3500001
UV CHAMBER
MAX FLOW RATE
300 l/h
NUMBER OF LAMPS
1 x 12 W
NUMBER OF LAMPS
1 x 16 W
LAMP LIFE-SPAN UV-C DOSE
9000 HOURS
≥ 300 J/m
2
TRANSFORMER
Electrical supply: 230V - 50/60 Hz
Red led of anomaly: YES
Connecting wire: 90 cm
LAMP LIFE-SPAN UV-C DOSE
9000 HOURS
≥ 300 J/m
2
TRANSFORMER
Electrical supply: 230V - 50/60 Hz
Red led of anomaly: SI
Connecting wire: 90 cm
ELECTRICAL ABSORPTION
12 Wh
ELECTRICAL ABSORPTION
Material: AISI 304 - optional AISI 316L
IN / OUT: 1/8” F
Working pressure: 9 bar
UV 600 AL
STERILIZERS WITH BALLAST
CODE
EA3500002
UV CHAMBER
MAX FLOW RATE
600 l/h
16 Wh
Material: AISI 304 - optional AISI 316L
IN / OUT: 1/2” M
Working pressure: 9 bar
Dose valid with transmittance 99% at 1 cm - T 20°C - after 9000 hours
UV 1200 - UV 2800
UV 1200 LCD
STERILIZERS WITH CONTROL PANEL
CODE
MAX FLOW RATE
EA3500003
1200 l/h
UV CHAMBER
Material: AISI 304 - optional AISI 316L
IN / OUT: 3/4” M
Working pressure: 9 bar
UV 2800 LCD
STERILIZERS WITH CONTROL PANEL
CODE
MAX FLOW RATE
EA3500004
2800 l/h
UV CHAMBER
Material: AISI 304 - optional AISI 316L
IN / OUT: 1” M
Working pressure: 9 bar
ELECTRICAL
PANEL
LCD / LCD PLUS
ELECTRICAL
PANEL
LCD / LCD PLUS
NUMBER
OF LAMPS
1 x 30 W
NUMBER
OF LAMPS
1 x 40 W
LAMP
LIFE-SPAN
9000 HOURS
LAMP
LIFE-SPAN
9000 HOURS
UV-C DOSE
≥ 300 J/m
2
UV-C DOSE
≥ 300 J/m
2
ELECTRICAL
ABSORPTION
30 Wh
ELECTRICAL
ABSORPTION
40 Wh
Dose valid with transmittance 99% at 1 cm - T 20°C - after 9000 hours
CONTROL PANEL
LCD CONTROL PANEL
electrical alimentation 230V - 50/60 Hz
protection degree IP55
power cable 100 cm
cable lamps 100 cm
LCD Display with microprocessor control
count down hour-meter
red led of anomaly
alarm relay free contact NO/NC
alarm relay 230 V NO/NC outlet - 2 A max
LCD PLUS CONTROL PANEL
electrical alimentation 230V - 50/60 Hz
protection degree IP55
power cable 100 cm
cable lamps 100 cm
LCD Display with microprocessor control
count down hour-meter
red led of anomaly
alarm relay free contact NO/NC
alarm relay 230 V NO/NC outlet - 2 A max
display of Irradiation / temperature control
shutdown for high temperature UV chamber
resettable count down hour-meter with alarm for end lamp life
335 | water treatment systems
