LPG

Technical Details

5.0

FLEXWELL®-LPG Pipe Systems for Petrol Station

s

Inhaltsverzeichni

s

LPG 5.0

Table of contents

LPG 5.1

System description

LPG 5.100

System description FLEXWELL®-LP

G

LPG 5.11

Product scheme

LPG 5.110

Pipelines, end couplings, straight couplings,

steel ducts

LPG 5.120 Pipeline

LPG 5.2

End couplings

LPG 5.201

with welding end, screwed, PN 25

LPG 5.211

with NPT thread, screwed, PN 25

as well as with NPT thread reduced, screwed

,

PN 25

LPG 5.221

with collar and split flange acc. to DIN EN 1092-1

,

screwed, PN 25

as well as with collar and split

flange acc. to

ANSI (300 lb/B16.5), screwed, PN 25

LPG 5.4

Formed componet

s

LPG 5.401

Straight couplings, screwed, PN 25

LPG 5.515

Steel duct and pipe sleev

e

LPG 5.5

Installation guide

LPG 5.500

Installation guide – safety requirements

,

requirements for the installer, trench, fixtures

LPG 5.505

Installation guide – safety measures prior t

o

laying of the pipe

LPG 5.52

Fluidic

s

LPG 5.520

Pressure loss diagram for

fluid propan

e

LPG 5.525

Pressure loss diagram for vaporized propan

e
