complementary pieces
Terminal
Extra Small/Small/Large
Extra Small:
26,9· H 1,5· 2,8 cm
11”· H 1”·2”
Small:
25,7· H 1,5· 2,8 cm
10”· H 1”·2”
Large:
24,6· H 1,5· 2,8 cm
10”· H 1”·2”
Listello di chiusura
9· 31,5· 0,6 cm
4”· 12”·1”
Losange
Laying and maintenance tips
504
ROMBINI
ROMBINI
505
Closing piece available in all colours of the collection.
1 piece of Terminal Small is modular with 7 pieces of Triangle
Small. 1 piece of Terminal Large is modular with 4 pieces
of Triangle Large. 1 piece of Terminal Extra Small
is modular with 12 pieces of Triangle Extra Small.
use
installation
recommended adhesive
recommended joints
recommended fillers
cleaning at the end
of installation
general cleaning
(installed tiles)
calibers (real size)
Floor, wall – indoor, outdoor.
Lay on perfectly flat, dry walls
NON-RAPID-DRYING adhesive for porcelain stoneware to make it easier to fix the sheets.
Place the sheets with the same joint as within the sheet.
CEMENT-BASED GROUT: wash thoroughly with clean water.
Remove all traces of grout carefully before it dries completely.
EPOXY GROUT: wash thoroughly with clean water.
Remove all traces of grout carefully before it dries completely.
CEMENT-BASED GROUT: Buffered acid (e.g. DETERDEK PRO by FILA, or similar). Wet the floor with water, dilute the product 1:5 with water
and pour it on the floor. Wait for 2 or 3 minutes then use a white scotch brite pad and rinse well with clean water.
EPOXY GROUT: Alkaline detergent (e.g. FILA CR10 by FILA). FILA CR10: apply pure, wait for 30 minutes then use a green scotch brite
pad. SILICONE: Solvent for silicone (e.g. FILA ZERO SIL.). Pour it straight onto the stain, wait for 20 minutes and remove the mark using
scotch brite. PAINT: Can usually be removed using water, but if resin-based paints or particular enamels have been used, it is best to ask the
manufacturer which solvent is most suitable. RUST: stain remover es. FILA NO RUST. Apply the product onto the stain, leave for 15 minutes,
remove the residue and rinse thoroughly.
You are recommended to use ordinary neutral detergent diluted in water. Avoid using acid or alkaline products, waxes and/or impregnants.
During ordinary cleaning it is recommended to use extremely abrasive items (such as scourers and iron or steel sponges) as little as possible.
This recommendation must be adhered to rigorously in the case of tiles with a glossy surface finishing as they are more susceptible to the risk
of scuffs, scratches and loss of shine, etc. In the event of heavy dirt or particularly textured surfaces, use an alkaline detergent and rinse after
washing. For large surfaces, the use of a floor washing machine is recommended. During every-day cleaning procedures, it is necessary to
remember that certain types of dirt (dust, sand) increase the abrasive effect of foot-traffic. Therefore we recommend that you avoid bringing in
this type of dirt, which comes in from the outside, by placing a door-mat at the entrance.
–
Extra Small
26,9
section
1
Small
25,7
section
Large
24,6
section
Listello with a glazed edge to be used in the corner as wall closure
or as a connector between Triangle (Small, Extra Small and Large)
and Losange. Available in all colours of the collection.
glazed edge
31,5
0,6
Triangle
Laying and maintenance tips
9
2,8
2,8
2,8
1,5
1
1,5
1
1,5
use
installation
recommended adhesive
recommended joints
recommended fillers
cleaning at the end
of installation
Wall – indoor.
Lay on perfectly flat, dry walls.
NON-RAPID-DRYING adhesive for porcelain stoneware to make it easier to fix the sheets.
Place the sheets with the same joint as within the sheet.
FINE-GRAIN CEMENT BASE GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water.
Remove all traces of grout carefully before it dries completely.
EPOXY GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water.
Remove all traces of grout carefully before it dries completely. Do not use for Triangle Vert and Triangle Brun.
– Triangle Vert and Triangle Brun: do not use abrasive cleaners / do not use acid or alkaline products. / Craquelé is a type of glazed
ceramics characterised by micro-cracks on the surface, deliberately created as a distinctive finish. This particular process makes the material
sensitive to acids. For ordinary maintenance, anti-limescale products should be avoided, because they can dull the surface.
Please proceed as follows:
1. Treatment pre-grouting with FILA MP90, solvent based stain protector.
2. Grouting with cement-based grout, possibly do not grout in contrast
3. Cleaning at the end of installation with cleaner FILA CLEANER PRO, neutral detergent, dilute the product in a ratio 1:30
4. Final cleaning with FILA MP90
– Triangle Matt and Glossy: do not use abrasive cleaners, expecially for glossy finishing.
FINE-GRAIN CEMENT BASE GROUT: Buffered acid (e.g. Deterdek by FILA, Deltaplus by KERAKOLL, or similar). Wet the floor with water,
dilute the product 1:5 with water and pour it on the floor. Wait for 5 minutes then use a white scotch brite pad and rinse well with clean water.
EPOXY GROUT: Alkaline detergent (e.g. Fugasoap by KERAKOLL, PS/87 by FILA). Wet the floor with water, dilute the product 1:5 with water
and pour it on the floor. Wait for 5 minutes then use a white scotch brite pad and rinse well with clean water. SILICONE: Solvent for silicone
(e.g. Remosil). Pour it straight onto the stain, wait for 1-2 minutes and remove the mark using scotch brite. PAINT: Can usually be removed
using water, but if resin-based paints or particular enamels have been used, it is best to ask the manufacturer which solvent is most suitable.
Triangle Vert and Triangle Brun: do not use abrasive cleaners / do not use acid or alkaline products
For ordinary maintenance, anti-limescale products should be avoided, because they can dull the surface.
Triangle Matt and Glossy: do not use abrasive cleaners, expecially for glossy finishing
–
general cleaning
(installed tiles)
calibers (real size)
