Technical features
STANDARD
ISO 10545/3
ISO 10545/6
ISO 10545/9
ISO 10545/12
ISO 10545/13
ISO 10545/14
DIN 51130 - 04
DIN 51097
DCOF
LEED CERTIFICATION 4.1
ENVIRONMENTAL MANAGEMENT
SYSTEM ISO 14000 AND ISO 9001
Robinson Test
VOC Emission
Declaration of Contents
EPD
SDS
BPD3
HPD
Packing
SIZE
120·120 cm
120·240 cm
60·60 cm
FEATURES
water absorption
resistance to deep abrasion UGL
resistance to thermal shock
frost resistance
resistance to acids and alkalis
(low and high concentration)
resistance to household cleaning agents and
swimming pool chemicals
VALUE REQUIRED
< 0,5%
≤ 175mm
3
no visible alteration
no visible alteration
PRIMAVERA
in conformity with standard
in conformity with standard
resistant
resistant
A
A
A
A
5
R9
–
0,51
14% recycled material
heavy use
available upon request
available upon request
available upon request
available upon request
available upon request
available upon request
Punto
collection
design
production
material
thickness
sizes
specification
use
awards
category
patents
PUNTO UP
Punto
Ronan & Erwan Bouroullec, 2021
Industrial
Glazed pressed body
Punto Down 13 mm – Punto Up 15 mm
Punto Down: 5 pcs 31,5·4·1,3 cm (12’’· 1,6’’· 0,5’’) on net: 21,1·31,5 cm (8’’· 12’’)
Punto Up: 5 pcs 31,5·4·1,5 cm (12’’· 1,6’’· 0,5’’) on net: 21,1·31,5 cm (8’’· 12’’)
– 2 shapes: up and down
– 5 matt colours: white, grey, red, blue, green
– 3 glossy colours: blanc, gris, rose
– 2 glossy colours with craquelé glaze: vert and brun
Wall – indoor
Best of Year 2022
BIII UNI EN 14411 GL
Registered design n° 009069826 – 001/0008 – date of registration: 27/06/2022
declared value
minimum class B
minimum 3
medium values
6÷10°
10÷19°
19÷27°
27÷35°
> 35°
–
> 0,42
Scan the QR code to
download the technical
features in other languages
stains resistance
slip resistance
R9
R10
R11
R12
R13
PUNTO DOWN
1net = 5 pcs
21,1·31,5·1,5
8’’·12’’·0,5’’
1net = 5 pcs
21,1·31,5·1,3
8’’·12’’·0,5’’
V3
moderate variation
Laying and maintenance tips
use
installation
recommended adhesive
recommended joints
recommended fillers
cleaning at the end
of installation
Wall – indoor
Lay on perfectly flat, dry walls.
PCS·SQM
0,69
0,35
2,77
PCS·BOX
2
1
4
SQM·BOX
2,88
2,88
1,44
BOX·PAL
20
22
44
KG·BOX
39,50
39,00
20
KG·PAL
790
858
880
SQM·PAL
57,60
63,36
63,36
NON RAPID DRYING adhesive for porcelain stoneware to make it easier to fix the sheets.
Place the sheets with the same joint as within the sheet.
FINE-GRAIN CEMENT BASE GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water. Remove all traces of grout carefully before
it dries completely. EPOXY GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water. Remove all traces of grout carefully before it
dries completely. Do not use for Punto Vert and Punto Brun.
– Punto Vert and Punto Brun: do not use abrasive cleaners / do not use acid or alkaline products. / Craquelé is a type of glazed ceramics
characterised by micro-cracks on the surface, deliberately created as a distinctive finish. This particular process makes the material sensitive to
acids. For ordinary maintenance, anti-limescale products should be avoided, because they can dull the surface.
Please proceed as follows:
1. Treatment pre-grouting with FILA MP90, solvent based stain protector.
2. Grouting with cement-based grout, possibly do not grout in contrast
3. Cleaning at the end of installation with cleaner FILA CLEANER PRO, neutral detergent, dilute the product in a ratio 1:30
4. Final cleaning with FILA MP90
– Punto Matt and Glossy: do not use abrasive cleaners, expecially for glossy finishing.
FINE-GRAIN CEMENT BASE GROUT: Buffered acid (e.g. Deterdek by FILA, Deltaplus by KERAKOLL, or similar). Wet the floor with water, dilute
the product 1:5 with water and pour it on the floor. Wait for 5 minutes then use a white scotch brite pad and rinse well with clean water. EPOXY
GROUT: Alkaline detergent (e.g. Fugasoap by KERAKOLL, PS/87 by FILA). Wet the floor with water, dilute the product 1:5 with water and pour
it on the floor. Wait for 5 minutes then use a white scotch brite pad and rinse well with clean water. SILICONE: Solvent for silicone (e.g. Remosil).
Pour it straight onto the stain, wait for 1-2 minutes and remove the mark using scotch brite. PAINT: Can usually be removed using water, but if
resin-based paints or particular enamels have been used, it is best to ask the manufacturer which solvent is most suitable.
Punto Vert and Punto Brun: do not use abrasive cleaners / do not use acid or alkaline products. For ordinary maintenance, anti-limescale products
should be avoided, because they can dull the surface. Punto Matt and Glossy do not use abrasive cleaners, expecially for glossy finishing.
–
general cleaning
(installed tiles)
calibers (real size)
494
PRIMAVERA
PUNTO
495
