Technical features
STANDARD
ISO 10545/2
ISO 10545/3
ISO 10545/4
ISO 10545/9
ISO 10545/12
ISO 10545/13
ISO 10545/14
DIN 51130
DIN 51097
DCOF
Pendulum BS
(EN 16165-c)
Pendulum AS/NZS
(4586313 app A)
Pendulum ES
(UNE 41901)
LEED CERTIFICATION 4.1
VOC Emission
EPD
Declaration of Contents
SVHC declaration
Packing
SIZE
Flower all colours net 41,1·23,5 cm
Seed all colours net 40,5·23,7 cm
FEATURES
SIZES
lenght and width
thickness
straigthness of edges
wedging
flatness
water absorption
breaking strength
modulus of rupture
resistance to thermal shock
frost resistance
resistance to acids and alkalis
(low and high concentration)
Resistance to household cleaning agents and
swimming pool chemicals
VALUE REQUIRED
BOTANICA
Chamotte
± 0,6%
± 5%
± 0,5%
± 0,5%
± 0,5%
< 0,5%
≥ 1300 N
≥ 32 N/mm
2
comply requirements
comply requirements
declared value
minimum class B
minimum class 3
in conformity with standard
0,2%
in conformity with standard
resistant
resistant
A
A
5
R9 matt
B matt
A glossy
0,52 matt
0,31 glossy
55/25 matt
dry/wet
57/23 glossy
dry/wet
26 P2 matt
23 P1 glossy
C1 matt/glossy
24%
Available upon request
Available upon request
Available upon request
Available upon request
Scan the QR code to
download the technical
features in other languages
collection
design
production
material
thickness
nominal sizes
specification
category
Chamotte
Patricia Urquiola, 2023
Artisanal
Glazed double-firing
approx. 9,70 mm (Mono), 10 mm (Linea), 10,70 mm (Quadra)
7,2·21,3 cm (3 ”·9”)
– 3 modules: Mono, Linea and Quadra
– 6 colours: Bianco, Blu, Terra, Ocra, Nero, Verde
UNI EN 14411:2016 App. L (BIIa Group) GL
stains resistance
> 0,42
Mono
7,2·21,3 cm
3”·9”
Linea
7,2·21,3 cm
3”·9”
Quadra
7,2·21,3 cm
3”·9”
Laying and maintenance tips
use
installation
recommended adhesive
recommended joints
recommended fillers
cleaning at the end
of installation
general cleaning
(installed tiles)
calibers (real size)
Walls, indoors
Lay on perfectly flat, dry walls
PCS·SQM
10,35
10,42
PCS·BOX
5
5
SQM·BOX
0,48
0,48
BOX·PAL
60
60
KG·BOX
8,50
8,25
KG·PAL
510
495
SQM·PAL
28,80
28,80
NON-RAPID-DRYING adhesive for porcelain stoneware to make it easier to fix the pieces.
Lay the pieces side by side without using spacers and making the installation uniform with the use of wedges. Proceed by arranging the tiles
carefully, frequently checking the alignments with a level. The use of grout is not mandatory.
FINE GRAIN CEMENT-BASED GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water. Remove all traces of grout carefully
before it dries completely.
EPOXY GROUT: Grout 0.5 m2 at a time and wash thoroughly with clean water. Remove all traces of grout carefully before it dries completely.
CEMENT-BASED GROUT: buffered acid (e.g. DETERDEK PRO by FILA or similar). Wet the floor with water, dilute the product 1:5 with water
and pour it on the floor. Wait for 2-3 minutes then use a white scotch brite pad and rinse well with clean water.
EPOXY GROUT: alkaline detergent (e.g. FILA CR10 by FILA). FILA CR10: apply pure, wait for 30 minutes then use a green scotch brite pad.
SILICONE: solvent for silicone (e.g. FILA ZERO SIL). Put it straight onto the stain, wait for 20 minutes and remove the mark using scotch brite.
PAINT: can usually be removed using water, but if resin-based paints or particular enamels have been used, it is best to ask the manufacturer
which solvent is most suitable.
RUST: stain remover (es. FILA NO RUST). Apply the product onto the stain, leave for 15 minutes, remove the residue and rinse thorough.
For routine cleaning avoid the use of more abrasive products (scouring pads, metal sponges) since it deals with tiles with glossy surface finish,
more susceptible to scratching, and may lose their shine, etc.
214,7x 72,4mm with +/- 1,8 mm tolerance
